Axis 01535-001 network switch Fast Ethernet (10/100) Power over Ethernet (PoE) Aluminium

Ex Connection Rail 4-Port PoE is a high performance PoE switch and 24 V DC power supply for hazardous areas. It is designed to connect explosion-protected network cameras over long distances. The network connection can be realized via optical fiber or copper-bound Ethernet, and is available for single-mode or multi-mode fiber. The power supply provides additional power to the cameras heater to extend the temperature range. The Ex d-rated enclosure is made from seawater-resistant copper-free aluminum and is ready for wall mounting.

2 IN STOCK

SKU: 01535-001

Manufacturer: Axis Axis

RRP Price €10,181.29

Specifications

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity
4
Basic switching RJ-45 Ethernet ports type
Fast Ethernet (10/100)

Network

Networking standards
IEEE 802.3at
10G support
No
Copper ethernet cabling technology
10BASE-T, 100BASE-FX, 100BASE-TX

Design

Product colour
Aluminium
Housing material
Aluminium

Power

AC input voltage
100 - 240 V
Output voltage
24 V

Power over Ethernet (PoE)

Power over Ethernet (PoE)
Yes
Power over Ethernet (PoE) power per port
30 W
Total Power over Ethernet (PoE) budget
120 W

Operational conditions

Operating temperature (T-T)
-60 - 50 °C
Storage temperature (T-T)
-60 - 50 °C
Operating relative humidity (H-H)
10 - 100%

Weight & dimensions

Width
289 mm
Depth
289 mm
Height
227 mm
Weight
16 kg

Certificates

Certification
ATEX, IECEx, EAC

Logistics data

Harmonized System (HS) code
85176990
