10F-DP14-EXTEND-CBL - Cables & Adaptors by StarTech.com

Extend a DisplayPort 1.4 connection or safeguard against port/connector strain

This high quality DisplayPort 1.4 Extension Cable provides extra reach for greater setup versatility, and reduces wear and tear of the DP port on your monitor or other devices. The connector markings enable quick visual identification, distinguishing this cable from other similar-looking or unmarked DisplayPort cables. Eliminate guesswork and always choose the appropriate cable to support full DP 1.4 performance.

Full DisplayPort Capability

This male-to-female DisplayPort extension cable supports all DisplayPort 1.4 features:

• Resolutions up to 8K 60Hz or 4K 144Hz
• High speeds with a bandwidth of up to 32.4Gbps
• Multi-Stream Transport (MST) for daisy-chaining multiple monitors
• High Dynamic Range (HDR) for higher contrast ratio and vivid colors
• Crystal-clear sound with up to 32 digital audio channels

This DisplayPort extension cable is backwards compatible with earlier versions of DisplayPort, ensuring seamless integration with existing DisplayPort devices.

The StarTech.com Advantage

7 IN STOCK

RRP Price €37.18

Specifications

Features

Connector 1 form factor
Straight
Connector 2 form factor
Straight
Connector contacts plating
Gold
DisplayPort version
1.4
Maximum resolution
7680 x 4320 pixels
Supported graphics resolutions
3840 x 2160, 7680 x 4320
Maximum refresh rate
144 Hz
Cable length
3 m
Connector 1
DisplayPort
Connector 2
DisplayPort
Connector 1 gender
Male
Connector 2 gender
Female
Product colour
Black
Cable material
Copper
Cable shielding
Aluminum mylar foil
Jacket material
Thermoplastic elastomer (TPE)
AWG wire size
30
High Dynamic Range (HDR) supported
Yes
Bandwidth
32400 MB/s
Multi-Stream Transport (MST)
Yes
Fire-resistance rating
VW-1

Operational conditions

Operating temperature (T-T)
0 - 50 °C
Storage temperature (T-T)
-20 - 70 °C
Operating relative humidity (H-H)
5 - 85%

Certificates

Compliance certificates
CE, RoHS

Sustainability

Doesn't contain
Halogen

Weight & dimensions

Cable diameter
8.4 mm
Weight
240 g

Packaging data

Package width
220 mm
Package depth
200 mm
Package height
20 mm
Package weight
246 g

Logistics data

Master (outer) case width
500 mm
Master (outer) case length
320 mm
Master (outer) case height
210 mm
Products per master (outer) case
40 pc(s)

Accessories
