30GA000LPB - Computer Systems by Lenovo

ThinkStation P5Powered for modern businesses, the brand-new ThinkStation P5 features dependable power, performance and security at its best. The up to 1 Intel Xeon W-2400 series processor supports up to 24 cores and delivers top-notch productivity in any workspace. Its HD Realtek audio and 1.5W speakerbring massive, detailed soundstage that takes online streaming and conferencing to the next level. Security features, including the Discrete TPM 2.0 chip, Kensington security slot and chassis intrusion switch provide end-to-end protection against device and data theft.Whether working from remote job locations or a corporate space, the Intel Wi-Fi 6E feature enables consistent speed and strong bandwidth at all times. The front and rear connectivity ports, including USB-C 3.2 Gen 2 allow seamless data transfer and connectivity to monitors and peripherals.With up to 512GB DDR5 memory support and up to 4TB storage, this workstation lets users multitask and switch between applications without having to worry about performance and speed.It has up to 512 DDR5 GB memory, supports up NVIDIA RTX A6000 graphics, up to 1 Intel Xeon processor as well as up to 4TB SSD storage, which make it a powerful workstation that breezes through compute-intensive tasks or heavy-duty applications easily.

ON ORDER

RRP Price €0.00

Specifications

Processor

Processor manufacturer
Intel
Processor family
Intel Xeon W
Processor model
w3-2435
Processor cores
8
Processor threads
16
Processor boost frequency
4.5 GHz
Processor frequency
3.1 GHz
Performance cores
8
Processor cache
22.5 MB
Processor cache type
Smart Cache
Processor base power
165 W
Maximum turbo power
198 W

Memory

Internal memory
32 GB
Maximum internal memory
512 GB
Internal memory type
DDR5-SDRAM
Memory layout (slots x size)
2 x 16 GB
Memory slots
8x DIMM
Memory clock speed
4800 MHz
ECC
Yes
Non-ECC
No
Memory channels
Quad-channel
Memory data transfer rate
4800 MT/s

Storage

Total storage capacity
1 TB
Storage media
SSD
Optical drive type
No
Number of storage drives installed
1
Total SSDs capacity
1 TB
Number of SSDs installed
1
SSD capacity
1 TB
SSD interface
PCI Express 4.0
NVMe
Yes
SSD form factor
M.2
M.2 SSD size
2280 (22 x 80 mm)
Card reader integrated
Yes

Graphics

Discrete graphics card
No
On-board graphics card
No
Discrete graphics card model
Not available
On-board graphics card model
Not available

Network

Ethernet LAN
Yes
Ethernet LAN data rates
100,1000 Mbit/s
Cabling technology
10/100/1000Base-T(X)
LAN controller
Intel® I219-LM
Wi-Fi
No

Ports & interfaces

USB 2.0 ports quantity
2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
5
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
2
USB 3.2 Gen 2x2 Type-C ports quantity
1
Ethernet LAN (RJ-45) ports
1
Line-out
Yes
Line-in
Yes
Combo headphone/mic port
Yes
Number of rear USB ports
6
Number of front USB ports
4

Expansion slots

PCI Express x4 (Gen 4.x) slots
3
PCI Express x8 (Gen 4.x) slots
1
PCI Express x16 (Gen 5.x) slots
2

Design

Chassis type
Tower
Volume
33 L
Placement supported
Horizontal/Vertical
Cable lock slot
Yes
Cable lock slot type
Kensington
Product colour
Black, Red

Performance

Motherboard chipset
Intel W790
Audio chip
Realtek ALC897-Q
Audio system
High Definition Audio
Built-in speaker(s)
Yes
Number of speakers
1
Password protection
Yes
Password protection type
BIOS, Power on, Supervisor
BIOS type
UEFI
Trusted Platform Module (TPM)
Yes
Product type
Workstation
Trusted Platform Module (TPM) version
2.0

Software

Operating system architecture
64-bit
Operating system language
English, Polish
Operating system installed
Windows 11 Pro for Workstations

Power

Power supply
1000 W
80 PLUS certification
80 PLUS Platinum

Operational conditions

Operating temperature (T-T)
10 - 35 °C
Storage temperature (T-T)
-40 - 60 °C
Operating relative humidity (H-H)
20 - 80%
Storage relative humidity (H-H)
10 - 90%
Operating altitude
0 - 3048 m
Non-operating altitude
0 - 12192 m

Certificates

Compliance certificates
RoHS

Sustainability

Sustainability certificates
TCO, ENERGY STAR, EPEAT Gold

Weight & dimensions

Width
165 mm
Depth
453.9 mm
Height
446 mm
Weight
19 kg

Packaging content

Mouse included
Yes
Mouse connectivity
Wired
Keyboard included
Yes
Keyboard connectivity
Wired

Display

Display included
No
