StarTech.com 25m (82ft) LC/UPC to LC/UPC OM4 Multimode Fiber Optic Cable, 50/125µm LOMMF/VCSEL Zipcord Fiber, 100G, Low Insertion Loss - LSZH Fiber Jumper Cord

StarTech.com 25m (82ft) LC/UPC to LC/UPC OM4 Multimode Fiber Optic Cable, 50/125µm LOMMF/VCSEL Zipcord Fiber, 100G, Low Insertion Loss - LSZH Fiber Jumper Cord

Name: StarTech.com 25m (82ft) LC/UPC to LC/UPC OM4 Multimode Fiber Optic Cable, 50/125µm LOMMF/VCSEL Zipcord Fiber, 100G, Low Insertion Loss - LSZH Fiber Ju...
Brand: StarTech.com
SKU: 450FBLCLC25
Price: 72.89 EUR
Availability: InStock

LSZH Jacket | Aramid Fiber Sheath | Ideal for SANs, data servers, SFP+

The LC to LC Multimode Duplex Fiber Optic Patch cable facilitates reliable connectivity across 40 and 100 Gigabit networks.

Engineered for Optimal Performance

With laser-optimized multimode fiber (LOMMF), the OM4 fiber patch cable is ideal for 850 nm and 1350 nm Vertical Cavity Surface Emitting Laser (VCSEL) and LED sources. Precision-manufactured ceramic ferrules ensure correct fiber alignment to prevent connectivity issues and minimize insertion loss. Designed for reliability in high-density network applications, the LC to LC UPC polished fiber ends greatly improves return loss characteristics over older PC polishing techniques which may negatively affect performance.

Wide Compatibility

This multimode 50/125µm fiber optic patch cord is backward compatible with OM3 and 1/10/40 Gbps networks, ensuring a reliable connection with legacy fiber environments.

Flame Resistant

Housed in a LSZH (Low-Smoke, Zero-Halogen) flame-retardant jacket, this OM4 fiber cable emits low smoke and toxic fumes when exposed to high heat or in the event of a fire. It enables safer cable installations in areas with poor ventilation including some industrial settings, self-contained environments such as trains and aircraft, as well as residential settings where building codes are a consideration.

Each OM4 fiber cable is also individually tested and certified to be within acceptable optical insertion loss limits for guaranteed compatibility and 100% reliability.

The StarTech.com Advantage

2 IN STOCK

SKU: 450FBLCLC25

Manufacturer:

StarTech.com

RRP Price €72.89

Specifications

Features

Cable length

25 m

Fibre optic type

OM4

Connector 1

Connector 2

Connector 1 gender

Male

Connector 2 gender

Male

Product colour

Aqua colour

Full duplex

Yes

Core diameter

50 µm

Cladding diameter

125 µm

Fiber mode structure

Multi-mode

Wavelengths supported

850,1300 nm

Data transfer rate

100 Gbit/s

Jacket material

Low smoke zero halogen (LSZH)

Sustainability

Sustainability compliance

Yes

Certificates

Compliance certificates

CE, RoHS

Operational conditions

Operating temperature (T-T)

-20 - 60 °C

Storage temperature (T-T)

-20 - 60 °C

Weight & dimensions

Cable diameter

2.9 mm

Bending radius

6 cm

Packaging data

Package width

330 mm

Package depth

255 mm

Package height

51 mm

Package weight

342 g

Packaging content

Quantity per pack

1 pc(s)

Logistics data

Master (outer) case width

410 mm

Master (outer) case length

410 mm

Master (outer) case height

450 mm

Products per master (outer) case

32 pc(s)

Description

Manufacturer

StarTech.com

WH1 (1–2 Days)

N/A

WH2 (1–3 Days)

WH3 (5–7 Days)

N/A

Weight

0.342 kg

Country of Origin

N/A

Datasheet

Data Sheet

Download
