Poynting OMNI-785 network antenna Omni-directional antenna RP-SMA 4 dBi

Poynting OMNI-785 network antenna Omni-directional antenna RP-SMA 4 dBi

Name: Poynting OMNI-785 network antenna Omni-directional antenna RP-SMA 4 dBi
Brand: Poynting
SKU: A-OMNI-0785-V1-01
Price: 18.14 EUR
Availability: OutOfStock

The OMNI-785 is a versatile omni-directional Wi-Fi antenna designed to enhance connectivity and improve transfer speeds for routers and modems. Covering the 2.4 GHz and 5 – 7.2 GHz Wi-Fi bands, this antenna ensures reliable performance for both older and modern dual-band Wi-Fi technologies.

Dual-Band Wi-Fi Connectivity: Supports 2.4 GHz and 5 – 7.2 GHz bands, ensuring strong and stable connections.
Peak Gain of 4 dBi: Provides enhanced signal strength and improved throughput across Wi-Fi networks.
Omni-Directional Design: Offers 360° coverage for optimal signal distribution and reduced dead zones.
Ground Plane Independent: Can be directly mounted on any equipment with an RP-SMA connector.
Flexible Deployment: Knuckle base allows multiple angle adjustments to accommodate various equipment orientations.
Universal Compatibility: Works with both older Wi-Fi technologies and dual-band Wi-Fi access points.
The OMNI-785 is an excellent solution for resolving channel saturation and optimising Wi-Fi performance, making it a reliable choice for high-speed, flexible wireless connectivity.

Ideal Applications
- On-the-go: Highly portable
- Poor data signal reception (indoor or outdoor)
- Slow or unstable data transmission connection
- Increase system transmission reliability
- M2M and IoT applications

ON ORDER

SKU: A-OMNI-0785-V1-01

Manufacturer: Poynting

RRP Price €18.14

Specifications

Performance

Frequency band

2.4 - 2.5 / 5 - 7.2 GHz

Antenna gain (2.4 GHz)

2 dBi

Antenna gain (5 GHz)

4 dBi

Impedance

50 Ω

Antenna gain level (max)

4 dBi

Wi-Fi standards

802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)

Features

Antenna type

Omni-directional antenna

Antenna connector type

RP-SMA

Connector gender

Male

Polarization

Linear, vertical

Voltage Standing Wave Ratio (VSWR)

<2.5:1

Product colour

Grey

Housing material

Acrylonitrile butadiene styrene (ABS)

International Protection (IP) code

IP55

Purpose

Indoor

Certificates

Certification

MIL-STD 810G/ASTM B117

Operational conditions

Operating temperature (T-T)

-40 - 80 °C

Operating relative humidity (H-H)

5 - 95%

Weight & dimensions

Depth

31 mm

Height

209 mm

Diameter

3.1 cm

Weight

40 g

Packaging data

Package width

250 mm

Package depth

45 mm

Package height

16 mm

Packaging content

Quantity per pack

1 pc(s)

Mounting brackets included

Yes

Description

Manufacturer

Poynting

WH1 (1–2 Days)

N/A

WH2 (1–3 Days)

N/A

WH3 (5–7 Days)

N/A

Weight

0.04 kg

Country of Origin

N/A

Datasheet

Data Sheet

Download

Accessories

No Accessories Found!

License

No License Found!
