Digitus USB 4.0 Type-C connection cable

Name: Digitus USB 4.0 Type-C connection cable
Brand: Digitus
SKU: DB-300443-010-S
Price: 28.35 EUR
Availability: OutOfStock

Supports the following transmission types: Audio/Video/Data transmission/Charging function

- Supports data transfer rates of up to 40 Gbit/s
- Supports USB Power Delivery Revision 3.1 (PD 3.1) with 20 V, 5A and 240W
- Backwards-compatible with Thunderbolt 3, USB 3.2, USB 3.1 and USB 2.0
- Supports DisplayPort (2.0) video/audio signals and PCi Express
- Video/audio support up to 8K (7680 × 4320 pixels at 60 Hz)
- USB-IF certified

The 3rd generation DIGITUS® USB 4.0 cable with aluminum housing is an all-rounder among cables. Thanks to the Thunderbolt 3 protocol, it can be used for PCI Express, DisplayPort and Host-to-Host transfers. With this cable, you can transfer audio/video signals, data as well as power. The data transfer speed is 40 Gbit/s, which makes the transfer speed 8x faster than USB 3.0 (5Gbit/s), 4x faster than USB 3.1 (10 Gbit/s) and 2x faster than USB 3.2 (20Gbit/s). This allows you to transfer large quantities of data such as films and music within seconds. Video signals are transmitted max. in 8K with a display refresh rate of 60 Hz. In addition, it also supports the resolution 4K (3840 x 2160) @60Hz (dual mode possible). Thanks to USB Power Delivery Revision 3.1, the fast charging function is ensured. With the corresponding charging device, you can charge your smart devices rapidly with max. 240 W (5 A / 48 V). The USB Type-C interface enables wide compatibility with devices with this connection.

ON ORDER

RRP Price €28.35

Specifications

Features

USB version

USB4 Gen 2x2

Connector 1

USB C

Connector 2

USB C

Connector 1 gender

Male

Connector 2 gender

Male

Connector 1 form factor

Straight

Connector 2 form factor

Straight

AWG wire size

Connector material

Aluminium

Connector contacts plating

Gold

Magnetically shielded

Yes

Cable jacket material

Polypropylene

Cable jacket type

Extremely flexible

Ferrite bead

Maximum data transfer rate

40000 Mbit/s

Maximum data transfer rate

40 Gbit/s

Product colour

Black

Cable type

Round cable

Plug and Play

Yes

USB Power Delivery (USB PD)

Yes

USB Power Delivery revision

3.0

USB Power Delivery up to

100 W

Maximum resolution

7680 x 4320 pixels

Maximum refresh rate

60 Hz

Weight & dimensions

Cable length

1 m

Cable diameter

5 mm

Bend radius (min)

6 cm

Packaging data

Package width

230 mm

Package depth

55 mm

Package height

20 mm

Package weight

77.312 g

Packaging content

Quantity per pack

1 pc(s)

Logistics data

Package volume

253 cm³

UK Trade Tariff code

85444290

Country of origin

China

Description

Manufacturer

Digitus

WH1 (1–2 Days)

N/A

WH2 (1–3 Days)

N/A

WH3 (5–7 Days)

N/A

Weight

0.077312 kg

Country of Origin

N/A

Datasheet

Data Sheet

Download
