Digitus CAT 6 U/UTP twisted pair patch cord, raw

Future-oriented standards and high-end quality for your network.

- Suitable for direct assembly of RJ45 connectors in order to produce patch cords
- Suitable for installations of class E cable lines, 250 MHz
- According to the norms ANSI/TIA-568-C; ISO/IEC 11801 2nd Ed.; EN 50173-1: EN 50288-6-1
- Conductor: Copper (Cu)
- PoE+ ready

The raw patch cords are manufactured and tested acc. to the ISO/IEC 11801 and DIN EN 50173 specifications. They will guarantee that the installed cabling system is compliant with the ISO & EN channel specification requirements and therefore provide optimum performance levels for your cablings.The raw patch cords are suitable for the direct assembly of RJ45 connector in order to produce patch cords.

1 IN STOCK

RRP Price €50.07

Specifications

Features

Product colour
Grey
Cable length
100 m
Cable standard
Cat6
Cable shielding
U/UTP (UTP)
Connector 1
No
Connector 2
No
Connector 1 gender
No
Connector 2 gender
No
Jacket material
Low smoke zero halogen (LSZH)
Conductor material
Copper
Twisted pair coupling type
4x2
Cabling technology
10GBase-T
Networking standards
IEEE 802.3, IEEE 802.5
AWG wire size
26/7
Data transfer rate
10000 Mbit/s
Frequency
250 MHz
Country of origin
China

Operational conditions

Operating temperature (T-T)
-10 - 60 °C
Storage temperature (T-T)
-10 - 75 °C

Weight & dimensions

Outer diameter
5 mm

Packaging data

Package width
270 mm
Package depth
270 mm
Package height
90 mm
Package weight
3.17 kg
Package volume
6561 cm³
Package type
Box

Other features

Input impedance
100 Ω
Category
6

Logistics data

Harmonized System (HS) code
84733080
UK Trade Tariff code
85444920
