DL3000EP - Computer Systems by Shuttle

The Shuttle XPC slim Barebone DL30N series is the successor to Shuttle's DL20N series. These fanless Slim PC barebones with an energy-efficient Intel 12th-Gen "Alder Lake-N" processor are suitable for building particularly slim PC systems with drives and operating system as well as client/server setups for pure network-based applications. Two Intel 2.5G LAN ports provide excellent network connectivity and the optional Shuttle accessory WWN03 allows for an LTE module to be installed for mobile internet access. The integrated graphics is based on Intel's powerful Intel UHD Graphics that supports hardware acceleration for 4K videos. Combined with an SSD drive, these Slim-PCs works virtually noiseless.

ON ORDER

RRP Price €476.04

Specifications

Processor

Processor manufacturer
Intel
Processor family
Intel® N
Processor model
N100
Processor cores
4
Processor threads
4
Processor boost frequency
3.4 GHz
Processor cache
6 MB
Processor cache type
Smart Cache

Memory

Internal memory
8 GB
Maximum internal memory
16 GB
Internal memory type
DDR5-SDRAM
Memory layout (slots x size)
1 x 8 GB
Memory slots
1x SO-DIMM
Memory clock speed
4800 MHz
Memory channels
Single-channel

Storage

Total storage capacity
128 GB
Storage media
SSD
Optical drive type
No
Number of storage drives installed
1
Total SSDs capacity
128 GB
Number of SSDs installed
1
SSD capacity
128 GB
SSD form factor
M.2

Graphics

On-board graphics card
Yes
Discrete graphics card model
Not available
On-board GPU manufacturer
Intel
On-board graphics card family
Intel® UHD Graphics
On-board graphics card model
Intel® UHD Graphics

Network

Ethernet LAN
Yes
Ethernet LAN data rates
100,1000,2500 Mbit/s
LAN controller
Intel I226-LM
Wi-Fi
No

Ports & interfaces

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
8
VGA (D-Sub) ports quantity
1
HDMI ports quantity
1
HDMI version
2.0b
DisplayPorts quantity
1
DisplayPort version
1.4a
Ethernet LAN (RJ-45) ports
2
Microphone in
Yes
Headphone outputs
1
DC-in jack
Yes
Serial ports quantity
2

Design

Chassis type
Slim PC
Volume
1.35 L
Cable lock slot
Yes
Cable lock slot type
Kensington
Product colour
Black
Housing material
Steel
Viewing window
No

Performance

Market positioning
Business
Audio chip
Realtek ALC888S
Password protection
Yes
BIOS type
UEFI AMI
Trusted Platform Module (TPM)
Yes
Product type
Mini PC
Trusted Platform Module (TPM) version
2.0

Software

Operating system architecture
64-bit
Operating system installed
Windows 10 IoT
Drivers included
Yes

Power

Power supply
65 W
Power supply input voltage
100 - 240 V
Power supply input frequency
50/60 Hz

Operational conditions

Operating temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
10 - 90%

Certificates

Compliance certificates
BSMI, CE, Federal Communications Commission (FCC), Low Voltage Directive (LVD), RCM, RoHS, UKCA, VCCI

Sustainability

Sustainability compliance
Yes
Sustainability certificates
ENERGY STAR, ErP

Weight & dimensions

Width
165 mm
Depth
190 mm
Height
43 mm
Weight
800 g
Package weight
2.1 kg

Packaging content

Cables included
AC
VESA mount included
Yes
Screws included
Yes

Logistics data

Harmonized System (HS) code
84714900

Display

Display included
No

Other features

Fanless
Yes

Accessories

License
