Kingston Technology ValueRAM memory module 32 GB 1 x 32 GB DDR5

This document describes ValueRAM's KVR52S42BD8-32 is a 4G x 64-bit (32GB) DDR5-5200 CL42 SDRAM (Synchronous DRAM), 2Rx8, memory module, based on sixteen 2G x 8-bit FBGA components. The SPD is programmed to JEDEC standard latency DDR5-5200 timing of 42-42-42 at 1.1V. Each 262-pin SODIMM uses gold contact fingers.

ON ORDER

RRP Price €102.08

Specifications

Features

Buffered memory type
Unregistered (unbuffered)
On-Die ECC
Yes
CAS latency
42
Internal memory
32 GB
Memory layout (modules x size)
1 x 32 GB
Internal memory type
DDR5
Component for
Laptop
Memory form factor
262-pin SO-DIMM
ECC
No
Memory ranking
2
Memory voltage
1.1 V
Module configuration
4096M x 64
SPD profile
Yes
Lead plating
Gold

Operational conditions

Operating temperature (T-T)
0 - 85 °C
Storage temperature (T-T)
-55 - 100 °C

Technical details

Compliance certificates
RoHS

Sustainability

Doesn't contain
Halogen

Weight & dimensions

Width
69.6 mm
Height
30 mm
