Peplink MAX BR1 Pro 5G Cellular network modem

Sonic for a Reason
The ‘classic goes sonic’, why? The BR1 Pro 5G is integrated with the new generation multi-core CPU ensuring delivery of gigabit speeds. Achieving 8 times faster than the original BR1 classic.

5G Adapter
Need a simple 5G adapter? Add a 5G WAN to any existing router or firewall without the need to replace any of your devices.

5G Router / Gateway
Why stop there? It can also serve as a powerful 5G router for your network. No matter if it’s C-Band or LTE, you’ll be able to add cellular connectivity easily to your network.

Fixed or Mobile
Supercharged with SpeedFusion, use the BR1 Pro 5G as the central router for your branch network. Guarantee unbreakable connections for important applications, like video calls, POS systems and more.

Wi-Fi 6
Experience less interference and connect to multiple devices simultaneously.

Deploy with Confidence
Just like the original BR1 Classic, the BR1 Pro 5G has also been certified to meet the standards of a wide array of deployment criterias.

Low-Profile Form Factor
At 1.15 inches short, the BR1 Pro 5G is 25% slimmer than the BR1 Classic.

963 IN STOCK

SKU: MAX-BR1-PRO-5GN-T-PRM

Manufacturer: Peplink Peplink

RRP Price €1,136.06

Specifications

Design

Device type
Cellular network modem
Product colour
Black
Built-in display
No

Ethernet LAN features

Ethernet LAN
Yes
Ethernet LAN interface type
Gigabit Ethernet
Ethernet LAN data rates
10,100,1000 Mbit/s

Wireless LAN features

Wi-Fi
Yes
Wi-Fi standards
Wi-Fi 6 (802.11ax)
Number of WLAN connections (max)
150

Mobile network

Data network
5G, LTE
Number of SIM cards
2
SIM card type
NanoSIM + eSIM

Ports & interfaces

Ethernet LAN (RJ-45) ports
3
USB port
No

Certificates

Compliance certificates
CE, Federal Communications Commission (FCC), RoHS
Certification
FCC, CE, RoHS, E-Mark EN61373 Shock and Vibration Resistance EN50155 Railway Applications Electronic Equipment used on Rolling Stock EN61000 Electromagnetic Compatibility EN45545-2 Railway applications - Fire protection

Performance

Antenna type
2x2
Antenna connector type
SMA/RP-SMA
Antennas quantity
7

Power

Power source type
AC
Power consumption (typical)
8 W
Input voltage
100 - 240 V

Operational conditions

Operating temperature (T-T)
-40 - 65 °C
Operating relative humidity (H-H)
15 - 95%

Weight & dimensions

Width
146.8 mm
Depth
129 mm
Height
29.3 mm
Weight
680 g

Logistics data

Warranty period
1 year(s)

Accessories

License
