StarTech.com Gigabit Ethernet Fiber Media Converter - Compact - 850nm MM LC - 550m

StarTech.com Gigabit Ethernet Fiber Media Converter - Compact - 850nm MM LC - 550m

Name: StarTech.com Gigabit Ethernet Fiber Media Converter - Compact - 850nm MM LC - 550m
Brand: StarTech.com
SKU: MCM1110MMLC
Price: 109.19 EUR
Availability: InStock

Convert and extend different networks over a Gigabit fiber cable connection up to 550m / 1804ft

This fiber media converter offers an easy, cost-effective way to extend your network over Gigabit fiber. It is equipped with a multimode transceiver which converts a copper RJ45 Ethernet connection to Gigabit fiber to extend your network over longer distances or connect workstations to switches. The converter provides a powerful extended networking solution for campuses, businesses, government facilities, stadiums, or other areas requiring network access.

Cost-effective extension and dependable performance

The Gigabit Fiber Media Converter provides a cost-effective and dependable solution for shorter range network extensions. It connects an Ethernet network to remote devices over a fiber backbone, with a 550m range on the fiber optic interface. The media converter has a durable metal housing, engineered to deliver long-lasting performance.

Versatile connections for broad compatibility

Fully compatible with 10/100/1000Base-T Ethernet networks, the fiber media converter supports auto negotiation to bridge different speed networks and devices to a Gigabit fiber network. It provides versatile connectivity to your existing networks and devices, allowing you to maximize the usage and performance of legacy equipment.

The multimode transceiver is removable, giving you the flexibility to change your transceiver in the future to meet your networking needs.

Easy installation and compact convenience

The unmanaged fiber media converter has a standalone design with simple plug-and-play set-up to ensure fast and easy installation. Compact in size, the converter gives you flexible installation options - including a wall mounting option to save space.

The MCM1110MMLC is backed by a StarTech.com 2-year warranty and free lifetime technical support.

The StarTech.com Advantage

- Convert between an RJ45 copper Ethernet connection and a fiber optic connection to extend your network cost-effectively
- 10/100/1000 Mbps RJ45 port supports auto negotiation to bridge different network speeds and devices to a Gigabit fiber network
- Compact standalone design and wall mounting option for easy and convenient installation

20 IN STOCK

RRP Price €109.19

Specifications

Network

Maximum data transfer rate

1000 Mbit/s

Converter input interface

1000Base-T, 100Base-TX, 10Base-T

Converter output interface

1000Base-LX, 1000Base-SX

Networking standards

IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3z

Ethernet interface type

Gigabit Ethernet

Ethernet LAN data rates

10,100,1000 Mbit/s

Data transfer rate

1000 Mbit/s

Jumbo frames support

Yes

Auto MDI/MDI-X

Yes

Duplex system

Full

Performance

Maximum transfer distance

550 m

Wavelength

850 nm

Wavelength-division multiplexing (WDM)

Fiber mode structure

Multi-mode

Mean time between failures (MTBF)

50000 h

Features

Internal

LED indicators

Activity, Link, Power

Product colour

Black

Housing material

Steel

Ports & interfaces

Connectivity technology

Wired

Ethernet LAN (RJ-45) ports

Fiber ports quantity

Fiber optic connector

DC-in jack

Yes

Power

Input voltage

100 - 240 V

Input current

1 A

Output voltage

5 V

Output current

2 A

Power over Ethernet (PoE)

External power adapter

Yes

Power plug type

Type N

Weight & dimensions

Width

70 mm

Depth

94 mm

Height

26 mm

Weight

201 g

Operational conditions

Operating temperature (T-T)

0 - 50 °C

Storage temperature (T-T)

-10 - 70 °C

Operating relative humidity (H-H)

5 - 95%

Packaging content

Manual

Yes

Packaging data

Package width

140 mm

Package depth

284 mm

Package height

68 mm

Package weight

556 g

Certificates

Compliance certificates

RoHS

Certification

CE, FCC, REACH, TAA

Logistics data

Harmonized System (HS) code

85176990

Description

Manufacturer

StarTech.com

WH1 (1–2 Days)

N/A

WH2 (1–3 Days)

WH3 (5–7 Days)

N/A

Weight

0.201 kg

Country of Origin

N/A

Datasheet

Data Sheet

Download
