N370X-10M - Cables & Adaptors by Eaton

40/100/400 GbE Cable Supports Higher Bandwidths for High-Density Data NetworkingThe N370X-10M is a premium multimode fiber optic cable that supports 400 Gb Ethernet speeds for transmitting data and voice signals over short distances. It is designed to support higher bandwidths for high-density patching between data center MDFs and IDFs in enterprise installations. This singlemode 9/125 OS2 cable is an ideal choice for 100 Gb Ethernet applications up to 100 meters (328 feet) at 1550 nm. It is also backward compatible with 10 Gb and 25 Gb networks, so you can future-proof your current application for an eventual upgrade to 100 Gb or 400 Gb.Switchable Connectors Allow Easy Polarity ConversionsThe switchable LC/UPC duplex ends let you easily switch the fiber polarity without tools or the need to re-terminate the connectors.Yellow Jacket Helps Avoid Misidentification That Can Cause Costly DowntimeThe OS2-rated cable has a yellow jacket to identify it as singlemode in a crowded patch panel or switch and prevent it from becoming accidentally disconnected. The round low-smoke zero-halogen (LSZH) jacket limits the amount of toxic smoke emitted in case of combustion, making it suitable for poorly ventilated areas.

ON ORDER

RRP Price €21.49

Specifications

Features

Cable length
10 m
Fibre optic type
OS2
Connector 1
LC
Connector 2
LC
Connector 1 gender
Male
Connector 2 gender
Male
Connector polish type
UPC
Cable type
OFNR
Product colour
Blue, Yellow
Core diameter
9 µm
Cladding diameter
125 µm
Fiber mode structure
Single-mode
Ethernet interface type
10 Gigabit Ethernet, 40 Gigabit Ethernet, 100 Gigabit Ethernet, 400 Gigabit Ethernet, Gigabit Ethernet
Data transfer rate
400 Gbit/s
Insertion loss
0.3 dB
Jacket material
Low smoke zero halogen (LSZH)

Sustainability

Sustainability compliance
Yes
Sustainability certificates
UL ECOLOGO

Certificates

Compliance certificates
RoHS, CE, REACH

Operational conditions

Operating temperature (T-T)
-20 - 60 °C
Storage temperature (T-T)
-20 - 60 °C

Weight & dimensions

Bending radius
2 cm

Packaging data

Package width
177.8 mm
Package depth
12.7 mm
Package height
228.6 mm
Package weight
90 g

Packaging content

Quantity per pack
1 pc(s)

Logistics data

Master (outer) case GTIN (EAN/UPC)
10037332271850
Country of origin
China
Master (outer) case width
152.4 mm
Harmonized System (HS) code
8544.70.0000
Master (outer) case length
154.9 mm
Master (outer) case height
185.4 mm
Master (outer) case gross weight
910 g
Products per master (outer) case
10 pc(s)
