StarTech.com PCI Express to 4 Slot PCI Expansion System

Add four external PCI expansion card slots to a desktop computer

StarTech.com's innovative PCI Express to PCI Expansion Chassis provides a quick and simple solution to I/O expandability on almost any PCI Express (PCIe) enabled system. Adding external PCI slots to a server/workstation or laptop, this cost-effective and time-saving method of simply adding additional PCI cards to a server/workstation or providing a platform to be able to swap PCI add-in cards between a mobile and desktop setup is the optimal method of maximizing the I/O capabilities of new or existing systems.

The external expansion chassis adds four PCI slots (32-bit/33MHz) to the host computer system, through a single PCI Express connection. Providing total bandwidth of up to 250MBps from the x1 PCIe host controller card, which allows the host computer to function as though the cards in the expansion chassis were connected directly to the motherboard. The PCIe controller card connects directly to the PCI Expansion box with an included DVI cable for a reliable, high quality connection.

A dependable I/O expansion solution, the Expansion Chassis is backed by StarTech.com's 2-year warranty and free lifetime technical support.

The StarTech.com Advantage

3 IN STOCK
SKU: PEX2PCI4
Manufacturer:
StarTech.com StarTech.com

RRP Price €552.57

Specifications

Design

Product colour
Black
Certification
CE, FCC, RoHS

Features

Plug and Play
Yes

Power

Output voltage
12 V
Output current
3 A

Operational conditions

Operating temperature (T-T)
0 - 55 °C
Storage temperature (T-T)
-40 - 75 °C

Weight & dimensions

Width
137 mm
Depth
204 mm
Height
142 mm
Weight
2.4 kg

Packaging data

Cables included
AC, DVI
Manual
Yes
Package width
200 mm
Package depth
245 mm
Package height
210 mm
Package weight
2.4 kg

Logistics data

Harmonized System (HS) code
84719000

Other features

Ports quantity
4

Accessories
