POESLT1G48V - Cables & Adaptors by StarTech.com

Rugged PoE Splitter | 12-48V DC | IP-30 Aluminum Housing | 1.5A Power Output

Splits a PoE connection (max 90W) into separate data (RJ45) and DC power (terminal block) that can power any device that uses DC power between 12V-48VDC (1.5A). Power non-PoE devices using network infrastructure, where power is not available.

Power Non-PoE Devices

Perfect for using PoE to power older devices while also providing network access for monitoring and control applications. Applications include:

Security (card swipe or proximity boxes)

Environmental monitoring (temperature/moisture sensors)

Telco (analog interface systems/conversion)

Straightforward Deployment

Supports IEEE 802.3af (PoE / Type 1), IEEE 802.3at (PoE+ / Type 2), and IEEE 802.3bt (PoE++ / Type 3) PoE inputs up to 90W and splits data and power. Power output via terminal block can be configured for 12/16/24/48V DC (1.5A).

The configuration is completed by DIP switches and the product can be wall or DIN rail mounted using the included hardware.

Designed for Harsh Environments

Industrial features include -40 C to 75 C operating temperature, IP-30 rated housing, vibration, shock, and free-fall standard testing.

Vibration: EN 60068-2-6

Shock: EN 60068-2-27

Free-Fall: EN 60068-2-32

600,000+ hours MTBF rating using Telcordia/Bellcore at 50 C for long-term reliability.

The POESLT1G48V is backed by a StarTech.com 2-year warranty and free lifetime technical support.

The StarTech.com Advantage

- HIGH POWER GIGABIT PoE SPLITTER: Power non-PoE devices using network infrastructure where power isn't available
- Splits PoE connection (max 90W) into RJ45 data & DC power (terminal block)
- 90W POE IEEE802.3bt: Supports IEEE 802.3af (PoE / Type 1), IEEE 802.3at (PoE+ / Type 2), IEEE 802.3bt (PoE++ / Type 3); power out configured w/ DIP switch for 12/16/24/48V DC (1.5A) via terminal block

6 IN STOCK

RRP Price €191.26

Specifications

Network

Ethernet interface type
Gigabit Ethernet
Ethernet LAN data rates
10,100,1000 Mbit/s
Cabling technology
10/100/1000Base-T(X)
Power over Ethernet (PoE)
Yes
Networking standards
IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Auto MDI/MDI-X
Yes
Duplex system
Full
Supported network protocols
CSMA/CD

Features

Product colour
Black
Surge protection
Yes
Maximum operating distance
100 m
LED indicators
Yes

Ports & interfaces

RJ-45 input ports
1
RJ-45 output ports
1

Power

Output current
1.5 A
Total Power over Ethernet (PoE) budget
90 W

Certificates

Compliance certificates
RoHS
Certification
CE, FCC, UL

Operational conditions

Operating temperature (T-T)
-40 - 75 °C
Operating relative humidity (H-H)
5 - 95%
Storage temperature (T-T)
-40 - 85 °C

Weight & dimensions

Width
81.5 mm
Depth
104 mm
Height
32 mm
Weight
150 g

Packaging content

Quick installation guide
Yes

Packaging data

Package length
21.1 cm
Package width
162 mm
Package depth
64 mm
Package weight
392 g

Logistics data

Harmonized System (HS) code
85044095

Accessories

License
