Tripp Lite U026-025 USB 2.0 Active Extension Repeater Cable (A M/F), 25 ft. (7.62 m)

Tripp Lite U026-025 USB 2.0 Active Extension Repeater Cable (A M/F), 25 ft. (7.62 m)

Name: Tripp Lite U026-025 USB 2.0 Active Extension Repeater Cable (A M/F), 25 ft. (7.62 m)
Brand: Eaton
SKU: U026-025
Price: 24.80 EUR
Availability: OutOfStock

The U026-025 USB 2.0 Hi-Speed Active Extension Cable (M/F) increases the length of a device cable an additional 25 feet (7.6 meters) with no danger of signal loss or decrease in performance. Connect the male plug to a USB port on your computer or hub and the female end to a USB device cable. A built-in bus-powered signal booster ensures peak USB 2.0 signal quality. Backward compatible with previous USB generations, this active USB extension cable supports data transfer rates up to 480 Mbps.

The U026-025 works with all computers, devices and cables with USB-A connectors, and provides up to 150mA of power to the connected device. An external power supply or powered USB 2.0 hub is necessary if the connected device requires more than 150mA.

Premium foil and braid shielding delivers reliable, error-free signal quality and protection from EMI/RFI line noise that can distort or destroy data. Molded gold-plated connectors with corrosion-resistant gold-plated contacts provide maximum conductivity and minimize data loss. Integral strain relief gives the cable extra flexibility, reduces stress, and helps the cable and connectors move freely without cracking.

ON ORDER

RRP Price €24.80

Specifications

Features

USB version

USB 2.0

Connector 1

USB A

Connector 2

USB A

Connector gender

Male/Female

Connector 1 gender

Male

Connector 2 gender

Female

Connector 1 form factor

Straight

Connector 2 form factor

Straight

Connector contacts plating

Nickel/Gold

Magnetically shielded

Yes

Maximum data transfer rate

480 Mbit/s

Maximum data transfer rate

0.48 Gbit/s

Product colour

Black

Plug and Play

Yes

Weight & dimensions

Cable length

7.62 m

Packaging data

Package type

Polybag

Package width

228.6 mm

Package depth

266.7 mm

Package height

12.7 mm

Package weight

360 g

Certificates

Compliance certificates

RoHS

Certification

CE, FCC

Logistics data

Products per master (outer) case

5 pc(s)

Master (outer) case GTIN (EAN/UPC)

10037332206937

Master (outer) case width

348 mm

Master (outer) case length

400 mm

Master (outer) case height

25.4 mm

Master (outer) case gross weight

1.68 kg

Harmonized System (HS) code

84733080

Country of origin

China

Description

Manufacturer

Eaton

WH1 (1–2 Days)

N/A

WH2 (1–3 Days)

N/A

WH3 (5–7 Days)

N/A

Weight

0.36 kg

Country of Origin

N/A

Datasheet

Data Sheet

Download
