U336-U03-GB - Cables & Adaptors by Eaton

U336-U03-GB - Cables & Adaptors by Eaton

Name: Tripp Lite U336-U03-GB USB to Gigabit Ethernet NIC Network Adapter with 3 Port USB 3.x (5Gbps) Hub
Brand: Eaton
SKU: U336-U03-GB
Price: 40.51 EUR
Availability: OutOfStock

The U336-U03-GB USB 3.0 SuperSpeed to Gigabit Ethernet NIC Network Adapter allows you to turn a single SuperSpeed USB 3.0 computer port into an RJ45 Gigabit network port. It also creates three new additional USB 3.0 hub ports with each port supporting data transfer speeds up to 5 Gbps.

This USB 3.0-based NIC lets you connect to your home or office network at full Gigabit speeds with support for 10/100/1000 Mbps. It supports features such as Wake-on-LAN (WoL), VLAN tagging and Jumbo Frames.

The U336-U03-GB is backward compatible with USB 2.0 and USB 1.x standards and will support older USB devices. It can also be used with older systems that do not have USB 3.0 ports (network speed limited by USB 1.x/2.0 bus), allowing you to utilize USB 3.0/2.0/1.x devices.

ON ORDER

RRP Price €40.51

Specifications

Ports & interfaces

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

Network

Ethernet LAN (RJ-45) ports

Networking standards

IEEE 802.3az

Performance

Product colour

Silver

Hub interfaces

USB 3.2 Gen 1 (3.1 Gen 1) Type-A

Country of origin

China

Power

AC input frequency

50 - 60 Hz

Output voltage

5 V

Output current

2.5 A

Software

Windows operating systems supported

Yes

Mac operating systems supported

Yes

Linux operating systems supported

Yes

Weight & dimensions

Width

44.4 mm

Depth

104.8 mm

Height

23.8 mm

Weight

68 g

Packaging data

Package width

73.7 mm

Package depth

144.8 mm

Package height

28.4 mm

Package weight

100 g

Technical details

Master (outer) case GTIN (EAN/UPC)

10037332182576

Logistics data

Products per master (outer) case

60 pc(s)

Master (outer) case width

302.3 mm

Master (outer) case length

289.6 mm

Master (outer) case height

251.5 mm

Master (outer) case gross weight

6.49 kg

Harmonized System (HS) code

84719000

Description

Manufacturer

Eaton

WH1 (1–2 Days)

N/A

WH2 (1–3 Days)

N/A

WH3 (5–7 Days)

N/A

Weight

0.068 kg

Country of Origin

N/A

Datasheet

Data Sheet

Download
