XH510G - Computer Systems by Shuttle

Name: Shuttle XPC slim Barebone XH510G - S1200, Intel H510, 1xDP, 1xHDMI, 1x PCI-E 16X, 1x LAN, 1x 2.5", 2x M.2, 24/7 permanent operation
Brand: Shuttle
SKU: XH510G
Price: 158.09 EUR
Availability: InStock

Flexible 3-litre PC with PCIe slot
The Shuttle XPC slim Barebone XH510G is a 3-litre PC to house one single-slot PCI-Express expansion cards. Together with an LGA 1200 Intel Core desktop processor of the Intel Core Gen 10/11 range, this platform is perfectly suited for many professional applica-tions where performance, flexibility and a compact form factor matter. This includes video wall presentations, graphics workstations, media capturing, surveillance, POS, POI as well as network and industrial applications. Even mid-range gaming is possible.

5 IN STOCK

RRP Price €158.09

Specifications

Processor

Built-in processor

Memory

Memory slots type

SO-DIMM

Number of memory slots

Maximum internal memory

64 GB

Supported memory clock speeds

2666,2933,3200 MHz

Supported memory types

DDR4-SDRAM

Memory channels

Dual-channel

Non-ECC

Yes

Storage

Supported storage drive types

HDD & SSD

Storage drive sizes supported

2.5,M.2

Storage drive interface

M.2, Serial ATA III

NVMe

Yes

Number of storage drives supported

Graphics

On-board graphics card

Yes

Graphics card family

Intel

Audio

Built-in speaker(s)

Network

Ethernet LAN

Yes

Wi-Fi

LAN controller

Intel® I219-LM

Ports & interfaces

USB 2.0 ports quantity

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

HDMI ports quantity

HDMI version

2.0a

DisplayPorts quantity

DisplayPort version

1.4

Microphone in

Yes

Headphone outputs

Ethernet LAN (RJ-45) ports

DC-in jack

Yes

Expansion slots

PCI Express slots version

4.0

PCI Express x16 slots

Design

Product colour

Black

Cooling type

Active

On/off switch

Yes

LED indicators

HDD, Power

Cable lock slot

Yes

Cable lock slot type

Kensington

VESA mounting

Yes

Product type

PC barebone

Performance

Motherboard chipset

Intel H510

Processor socket

LGA 1200 (Socket H5)

Number of processors supported

Compatible processor series

Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold

Trusted Platform Module (TPM)

Yes

Audio output channels

7.1 channels

Logistics data

Harmonized System (HS) code

84733080

Software

Windows operating systems supported

Windows 10, Windows 11

Linux operating systems supported

Yes

Operating system installed

Power

Power supply type

External AC adapter

Power supply

180 W

AC input voltage

100 - 240 V

AC input frequency

50 - 60 Hz

AC adapter output voltage

19.5 V

AC adapter output current

9.23 A

Operational conditions

Operating temperature (T-T)

0 - 50 °C

Operating relative humidity (H-H)

10 - 90%

Weight & dimensions

Width

250 mm

Depth

200 mm

Height

78.5 mm

Weight

3.2 kg

Packaging content

Power cord included

Yes

AC adapter included

Yes

Quick start guide

Yes

Drivers included

Yes

Other features

Country of origin

China

Description

Manufacturer

Shuttle

WH1 (1–2 Days)

N/A

WH2 (1–3 Days)

WH3 (5–7 Days)

N/A

Weight

3.2 kg

Country of Origin

N/A

Datasheet

Data Sheet

Download

Accessories

No Accessories Found!

License

No License Found!
