5PX1500RTG2 - UPS by Eaton

Introducing the latest addition to Eaton's 5 series UPS line, the Eaton 5PX G2 rackmount and tower UPS provides the maximum power possible at each power rating. The 5PX G2 UPS has power ratings ranging from 1 to 3 kVA, with low and high voltage options and offers up to four optional external battery modules for extra runtime. The 5PX G2 UPS has reduced depth to conserve space allowing for high desnisty wallmount rack options, with the 2 to 3 kVA models.Join the list to be first to know about the new Eaton 5PX G2 UPS.5PX G2 UPS features include:Deployment simplified: The 5PX G2 UPS offers mass UPS firmware upgrades without dropping the load and provides an easy startup configuration wizard simplifying your UPS setup process.Runtime: Increased standard runtime by at least 25% on 1.5 and 2 kVA models compared to the orginal 5PX UPSStay connected, securely: Reduce risk of intrusion with the optional Gigabit Network Card (NETWORK-M2), which is the first UPS connectivity device to meet both UL and IEC cybersecurity standardsEnhanced surge protection: The 5PX G2 provides enhanced surge protection keeping your branch offices and IT closets equiment safe

ON ORDER

RRP Price €1,558.82

Specifications

Features

UPS topology
Line-Interactive
Output power capacity
1.44 kVA
Output power
1440 W
Waveform
Pure sine
Input operation voltage (min)
120 V
Input operation voltage (max)
230 V
Input frequency
50/60 Hz

Ports & interfaces

AC outlet types
NEMA 5–15R
AC outlets quantity
6 AC outlet(s)
USB port
Yes
USB 2.0 ports quantity
1
USB port type
USB Type-B
Serial interface
Yes
Serial interface type
RS-232
Serial ports quantity
1
RS-232 ports
1

Battery

Battery technology
Sealed Lead Acid (VRLA)
Battery voltage
48 V
Typical backup time at full load
5 min
Typical backup time at half load
15 min

Design

Form factor
Rackmount/Tower
Rack capacity
2U
Product colour
Black, Silver
Display type
LCD

Packaging content

Rack mount kit
Yes
Cables included
RS-232, USB cable
Quick installation guide
Yes

Weight & dimensions

Width
436.9 mm
Depth
447 mm
Height
86.4 mm
Weight
23 kg

Logistics data

Harmonized System (HS) code
85078000

Accessories
