StarTech.com 16-Port USB-to-Serial Adapter Hub

StarTech.com 16-Port USB-to-Serial Adapter Hub

Name: StarTech.com 16-Port USB-to-Serial Adapter Hub
Brand: StarTech.com
SKU: ICUSB23216FD
Price: 692.10 EUR
Availability: InStock

Convert a USB port into 16 RS232 serial ports in an industrial rack-mountable chassis - and daisy chain multiple hubs for a scalable solution

Here's an easy and cost-efficient way to add RS232 serial capability to your industrial setting. This 16-port USB-to-serial adapter hub features a sturdy, rack-mountable chassis, and supports daisy chaining, so you can connect multiple hubs together to increase your serial device port count.

A scalable solution for changing needs

This rack-mountable USB serial hub lets you add 16 serial ports (RS232), with full control from your desktop or laptop computer system using a single USB port. The daisy-chain function gives you a cost-effective and scalable way to increase your serial port count and expand as your needs grow, without investing in a higher cost serial hub.

Providing full control of your serial components from a single device, the USB serial hub is ideal for a multitude of applications including: industrial automation, self-serve automated kiosks, and monitoring of cameras and security systems.

Built-in convenience

The hub features COM port retention, which retains the assigned serial COM port values. This ensures that the same values are automatically re-assigned to the port provided by the adapter, in the event it is disconnected and re-connected to the host computer.

Meets the demands of industrial environments

With its all-metal chassis, this rugged, rack-mountable hub fits into standard 19-inch server storage racks to provide an efficient industrial serial solution. It supports an extended operating temperature range of -40°C to 85°C (-40°F to 185°F); ensuring reliable performance even in the harshest environments. The USB-serial hub includes both an AC adapter and terminal block power, providing versatile power options.

The StarTech.com Advantage

5 IN STOCK

RRP Price €692.10

Specifications

Ports & interfaces

Host interface

USB 2.0 Type-B

Hub interfaces

Serial

Ports quantity

RS-232 ports

Terminal block port

Yes

DC-in jack

Yes

Features

Data transfer rate

480 Mbit/s

Product colour

Black

Housing material

Steel

LED indicators

Yes

Power

Power consumption (max)

36 W

Input voltage

100 - 240 V

Input current

1.5 A

Output voltage

12 V

Output current

3 A

Power plug type

Type N

System requirements

Windows operating systems supported

Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 2000, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 98SE, Windows CE, Windows Vista, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows Vista x64, Windows XP, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Mac operating systems supported

Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura

Linux operating systems supported

Yes

Server operating systems supported

Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019

Other operating systems supported

Windows XP Embedded

Weight & dimensions

Width

120 mm

Depth

430 mm

Height

45 mm

Weight

1.55 kg

Packaging data

Package width

215 mm

Package depth

451 mm

Package height

61 mm

Package weight

2.31 kg

Packaging content

AC adapter included

Yes

Included power plug types

AU, EU, NA, UK

Cables included

USB

Quick installation guide

Yes

Operational conditions

Operating temperature (T-T)

-40 - 85 °C

Storage temperature (T-T)

-65 - 150 °C

Operating relative humidity (H-H)

20 - 80%

Performance

Data bits

7, 8

Stop bits

1, 2

Parity bit

Even, Mark, No, Odd, Space

FIFO (First In, First Out)

256 B

Baud rate

921.6 Kbit/s

Mean time between failures (MTBF)

49337 h

Sustainability

Sustainability compliance

Yes

Logistics data

Master (outer) case width

341 mm

Master (outer) case length

477 mm

Master (outer) case height

238 mm

Products per master (outer) case

5 pc(s)

Harmonized System (HS) code

84719000

Technical details

Compliance certificates

CE, RoHS

Other features

Rack mounting

Yes

Chipset

FTDI - FT232RL

Description

Manufacturer

StarTech.com

WH1 (1–2 Days)

N/A

WH2 (1–3 Days)

WH3 (5–7 Days)

N/A

Weight

1.55 kg

Country of Origin

N/A

Datasheet

Data Sheet

Download
