StarTech.com 8 Port 1U Rackmount USB KVM Switch with OSD

StarTech.com 8 Port 1U Rackmount USB KVM Switch with OSD

Name: StarTech.com 8 Port 1U Rackmount USB KVM Switch with OSD
Brand: StarTech.com
SKU: SV831DUSBU
Price: 511.56 EUR
Availability: OutOfStock

Control up to 8 VGA and USB computers from a single keyboard, mouse and monitor
The SV831DUSBU 8 Port 1U Rack Mount USB KVM Switch with OSD offers a dependable computer management tool that allows you to control up to 8 USB-connected computers from a single keyboard, mouse and monitor.
The KVM switch offers maximum control, allowing you to switch computers using hotkey commands or front panel push-buttons, and offers added configuration options and convenience through an On Screen Display (OSD).
A suitable addition to server room operations, the 8 port switch can be rack mounted into 1U of cabinet space, and can be cascaded with multiple KVM switches to deliver control of up to 64 computers from this single switch.
Backed by a StarTech.com 3-year warranty and free lifetime technical support.
The StarTech.com Advantage
- Extracting the keyboard strokes from the USB connection this KVM enables hot key support for wireless keyboard and mouse combo kits that use a single USB receiver
- Cascade configuration supported for one spot control of up to 64 computers
- Rugged, rack mountable 1U metal chassis is ideal for any environment

ON ORDER

RRP Price €511.56

Specifications

Ports & interfaces

Number of computers controlled

Keyboard port type

USB

Mouse port type

USB

Video port type

VGA

VGA (D-Sub) ports quantity

Console ports

USB A, VGA (D-Sub)

Console USB ports quantity

Audio connections

DC-in jack

Yes

Performance

Maximum resolution

1920 x 1440 pixels

Plug and Play

Yes

Daisy chain

Yes

Design

Rack mounting

Yes

Rack capacity

Product colour

Black

Housing material

Steel

LED indicators

Yes

Mean time between failures (MTBF)

150000 h

Certification

CE, FCC, TAA, REACH

Display

Built-in display

On Screen Display (OSD)

Yes

Power

Input voltage

100 - 240 V

Input current

0.8 A

Output voltage

12 V

Output current

1.5 A

Power plug type

Type M

Compatible power plug types

EU, UK, US

Sustainability

Compliance certificates

RoHS

Operational conditions

Operating temperature (T-T)

5 - 40 °C

Storage temperature (T-T)

-20 - 60 °C

Operating relative humidity (H-H)

0 - 80%

Weight & dimensions

Width

540 mm

Depth

180 mm

Height

45 mm

Weight

2.9 kg

Packaging data

Package width

89 mm

Package depth

573 mm

Package height

268 mm

Package weight

3.3 kg

Packaging content

Manual

Yes

AC adapter included

Yes

Rubber feet

Yes

Other features

Connectivity technology

Wired

Dimensions (WxDxH)

540 x 180 x 45 mm

Ports quantity

Power requirements

110 - 240 AC

Audio support

IP control

Logistics data

Harmonized System (HS) code

85176200

Description

Manufacturer

StarTech.com

WH1 (1–2 Days)

N/A

WH2 (1–3 Days)

N/A

WH3 (5–7 Days)

N/A

Weight

2.9 kg

Country of Origin

N/A

Datasheet

Data Sheet

Download
